Savöx SW-0267MG WP (6.0kg/0.13s/6.0v) Servo

Description

Savöx SW-0267MG Waterproof Digital Micro Servo (6.0kg / 0.135s / 6.0V)

Product Code: SW-0267MG
EAN: 4710006994352

Description:
The Savöx SW-0267MG is a waterproof, high-torque digital micro servo designed for 1/18 and 1/16 scale RC vehicles. As a direct upgrade for the Traxxas 2065A servo, it offers enhanced performance and durability in a compact form. Its IP67-rated waterproof housing makes it ideal for use in all weather and off-road conditions.

Key Features:

• Powerful brushed DC motor
• Durable and precise metal geartrain
• Smooth operation with integrated ball bearings
• Lightweight composite case
• Fully waterproof design (IP67)

Technical Specifications:

• Torque:
  • @4.8V – 5.0 kg/cm
  • @6.0V – 6.0 kg/cm
• Speed (60° rotation):
  • @4.8V – 0.16 sec
  • @6.0V – 0.135 sec
• Dimensions (L x W x H): 22.6 x 12.6 x 23.5 mm
• Weight: 14 g
• Operating Voltage: 4.8V – 6.0V
• Gear Type: Metal Gears
• Case Material: Composite
• Waterproof Rating: IP67
• Connector: JR Universal
• Output Spline: 25T

Recommended Applications:

• Traxxas 1/18 and 1/16 scale models (e.g. TRX-4M, LaTrax Teton, Rally, Desert Prerunner)
• RC boats and watercraft
• Ideal for any small-scale RC application requiring high torque and waterproof protection

See also the original presentation from the manufacturer:

• Savöx RC Car servo SW-0267MG Waterproof
