SRT W35 (35kg/0.1s/8.4v) HV Waterproof Servo

Description

SRT W35 Waterproof servo is especially suitable as a steering servo for 1/10 scale RC Crawlers. Of course, this standard size SRT servo is also suitable for other RC models where up to 35kg of force is needed and 0.1s speed is sufficient.

SRT W35 Servo Features:

• Type: Digital
• Bearing: Dual
• Motor Type: Coreless
• Gear Type: Metal
• Gear Material: Titanium & Steel
• control system: pulse width control
• working frequence: 1520Œºs / 330hz
• operating voltage: dc6.0-8.4v
• operating temperature range: -10 to + 60 degree
• operating speed (6.0v): 0.15 sec/60 degrees at no load
• operating speed (7.4v): 0.12 sec/60 degrees at no load
• operating speed (8.4v): 0.10 sec/60 degrees at no load
• stall torque (6.0v): 25.0kg.cm (347.2 oz/in)
• stall torque (7.4v): 30.0kg.cm (416.6 oz/in)
• stall torque (8.4v): 35.0kg.cm (486.1 oz/in)
• potentiometer drive: direct drive
• Servo dimensions: 40.7x20.5x38.6 mm /1.60x0.81x1.52 in
• SRT W35 servo weight: 82.5g (2.91 oz)
• connector wire length: jr 360 mm
