Kyosho Ultima RB7.5 2WD 1:10 Competition Racing Buggy EP Kit

New 13 mm aluminum big-bore oil shocks with X-ring seals provide smoother operation and improved control through fast corners, uneven sections and jump landings. The front and rear shock towers are now manufactured from 4 mm carbon fiber, while new aluminum rear bulkhead components and rear hub carriers increase rigidity and provide additional suspension geometry adjustment options.

The low center of gravity, mid-motor layout and rigid duralumin main chassis give the RB7.5 precise and responsive handling. An updated aerodynamic body, stronger rear wing and standard front wing allow the aerodynamic balance to be adjusted according to track conditions and driving style.

The RB7.5 is a true competition-level 1:10 RC buggy kit, offering extensive setup possibilities for different track conditions. It is also compatible with a wide selection of Kyosho Ultima setup and optional upgrade parts.

Key Features

• 1:10 scale 2WD rear-wheel-drive competition buggy
• Mid-motor layout for a low center of gravity
• High-rigidity duralumin main chassis
• Independent double wishbone suspension front and rear
• New 13 mm aluminum big-bore oil shocks
• X-ring shock seals for smoother operation and improved oil retention
• 4 mm carbon fiber front and rear shock towers
• Front shock tower protector for increased protection during rollovers
• New aluminum rear hub carriers
• New aluminum rear bulkhead and upper-link mounting system
• Adjustable rear suspension geometry
• Aluminum steering crank and steering plate for precise and smooth steering
• Lightweight aluminum front axles
• Universal-type rear driveshafts
• Durable chromoly steel adjustable turnbuckles
• Adjustable rear toe angle and track width
• Laydown-type gearbox
• Ball differential
• Slipper clutch to protect the drivetrain from excessive loads
• High-precision tungsten differential balls
• LCG quick-release battery mounting system
• Adjustable battery position for front-to-rear weight balance tuning
• Updated clear aerodynamic body
• Reinforced rear wing
• Front wing included as standard
• Suitable for dirt tracks and easily adaptable for high-grip carpet and astro surfaces

Technical Specifications

• Scale: 1:10
• Drive system: 2WD / rear-wheel drive
• Type: Electric competition buggy kit
• Length: 395 mm
• Width: 249 mm
• Height: 148 mm
• Wheelbase: 277 mm
• Front track: 221 mm
• Rear track: 201 mm
• Spur gear: 72T
• Secondary gear ratio: 2.6:1
• Pinion gear: Sold separately
• Tires: Sold separately
• Motor: Sold separately
• Item code: K.34305B
• EAN: 4548565489800

Included in the Kit

• Kyosho Ultima RB7.5 unassembled chassis kit
• Clear unpainted polycarbonate body
• Front and rear wings
• Ball differential grease
• General-purpose grease
• 1.5 / 2.0 / 2.5 mm hex wrenches
• Cross wrench

Required for Operation

To complete and operate the model, the following items are required separately:

• 2–3 channel RC transmitter and receiver
• Steering servo
• Electronic speed controller (ESC)
• Suitable electric motor
• Pinion gear
• 1:10 buggy tires
• Tire inserts
• Drive battery
• Battery charger
• Polycarbonate body paint

The RB7.5 is a competition-level KIT model. Selecting the electronics, tires and drivetrain components separately allows the car to be built specifically for the track surface, racing class and individual driving preferences.
