Savöx SB-2292SG (45kg/0.055s/8.4V) Monster HV Brushless SG Servo

Its patented brushless motor and controller technology provide up to 35% more performance than previous-generation servos. The full aluminum case improves cooling and structural rigidity, while hardened steel gears and triple precision ball bearings ensure smooth operation and long-term durability under heavy loads.

The combination of high torque and rapid response makes the SB-2292SG an outstanding choice for both competition racing and demanding crawler applications.

Key Features

• Monster Series brushless servo
• High-voltage operation up to 8.4V
• Full aluminum case
• Hardened steel gears
• Triple precision ball bearings
• Extremely fast response
• High torque output
• High efficiency and low power consumption
• Ideal for racing and crawler applications
• 25T output spline

Specifications

• Servo Type: Digital HV Servo
• Motor Type: Brushless
• Gear Material: Steel
• Case Material: Full Aluminum
• Bearings: 3 Ball Bearings
• Operating Voltage: 6.0–8.4V
• Speed @ 6.0V: 0.085 sec / 60°
• Speed @ 7.4V: 0.07 sec / 60°
• Speed @ 8.4V: 0.055 sec / 60°
• Torque @ 6.0V: 22.0 kg-cm
• Torque @ 7.4V: 31.0 kg-cm
• Torque @ 8.4V: 45.0 kg-cm
• Dimensions: 40.3 × 20.2 × 38.7 mm
• Weight: 81 g
• Output Spline: 25T

Recommended Applications

• 1/8 Electric Buggies
• 1/8 Nitro Buggies
• 1/8 Truggies
• 1/8 GT Racing Cars
• 1/10 Crawlers
• 1/8 Crawlers
• Rock Crawlers
• 1/10 Monster Trucks
• High-performance off-road vehicles
