Hobbywing XeRun XR10 Pro G3-X ESC

Toote kirjeldus

XeRun XR10 Pro G3-X

• The G3 version comes standard with 13AWG wire, while the G3X version comes standard
  with 12AWG wire,and does not have Reverse Voltage Protection.
• The G3X is ideal for Stock competition, providing more aggressive power delivery.

Product Number: 30112620

Type:

• Scale: 1/10th
• Brushed/Brushless: BL
• Sensored/Sensorless: SD
• Waterproof: NO

Specifications:

• Cont./Peak Current: 160A/1200A
• Input Voltage: 2S Lipo
• BEC Output: Switch Mode 5V-7.4V @6A

Wires & Connectors:

• Input Wires: Black-12AWG-200mm*2
• Output Wires: Black-12AWG-200mm*3
• Input Connectors: No
• Output Connectors: No

ESC Programing via:

• SET Button on ESC: Not Supported
• LED Program Box: Not Supported
• LCD G2 Program Box: Supported
• LCD PRO: Supported
• OTA Programmer: Supported
• Program Port: Separate Program Port

Data Recording:

• Extreme value: Supported
• Real-time Data: Supported
• Historical data (Graph): Supported

Firmware:

• Firmware Upgrade: Supported

Size & Weight:

• Size: 35.0*33.6*30.3mm
• Weight: 101.5g(w/Wires)

Applications:

• Motors: Sensored brushless motors / Sensorless brushless motors
• Vehicles: 1/10th Touring car & Buggy racing;1/10th Drift,F1,Rally
• KV Rating/T Count: XERUN V10 G4R/G3, Bandit G4
