Description

AGF RC A280BHMW Aluminum Case Steel Gears Programmable HV 78KG Scale Servo

A280BHMW is a 2s version 5th scale servo. It combines long-life brushless motor with monster torque design takes the driving experience of large model enthusiasts to a new level. It is ideal for 1/5 Monster Truck, Buggy, Crawler, Large Airplanes, Robot Arm, etc. Whether you are traversing the jungle or climbing over sand dunes, strengthening gear structure improve the crashworthiness and life of the servo.

When you cross the mountains and pass the charming stream, fully magnetic waterproof IP67 grade can let your model play in humid environment or rainy day. This A280BHMW is suitable for most 1/5 scale models, which require to use with 2s lipo battery. Of course! In this era of rapid development, free choice is also a kind of happiness!

So how could we do without the programmable function? It is allow to be programmable via USB Programmer AGF-SP V3 now. In the near futuret it is available to be bluetooth APP programmable. Please don’t hesitate to add a reliable new partner to your model!

Features:

• Heat Sink Aluminum Case
• Extremely Strong Steel Gears
• 2S Lipo High Voltage Compatible
• Magnetic Sensor Waterproof IP67
• Available for Parameter Programmable (Please use with AGFRC USB Programmer AGF-SP V3).
• Bluetooth APP Programmable (Still not available now)

Note:

• 1) “Servo Neutral” function of AGFRC A280 Series 5th scale servos are not available to program, please well known before you order it.
• 2) Sanwa compatible: A280 Series servos is compatible with Sanwa SHR Mode only.

Specification:

• Item name: A280BHMW
• Operating Voltage: 4.8-8.4V
• Operating speed: 0.126 sec/60° @ 4.8V
• Operating speed: 0.110 sec/60° @ 6.0V
• Operating speed: 0.095 sec/60° @ 7.4V
• Operating speed: 0.082 sec/60° @ 8.4V
• Stall Torque: 48.0 kg-cm (667 oz-in)  @ 4.8V
• Stall Torque: 58.0 kg-cm (806 oz-in)  @ 6.0V
• Stall Torque: 66.0 kg-cm (917 oz-in)  @ 7.4V
• Stall Torque: 78.0 kg-cm (1084 oz-in) @ 8.4V
• Gear: Steel
• Motor: Brushless
• Size: 65.8*30.0*59.0mm(2.59 x 1.18 x 2.32 in)
• Weight: 284.8g
• Connector Wire: TYU 300mm / 22AWG
